Main Features
· Quick opening and closing: The valve can be fully opened or closed by rotating the stem only 90°, enabling fast operation.
· Extremely low flow resistance: When fully open, the valve passage is basically consistent with the pipe diameter, resulting in nearly zero fluid resistance and small pressure drop.
· Reliable sealing: When soft seals (such as PTFE) are adopted, zero leakage can usually be achieved with excellent sealing performance.
· Simple structure and easy maintenance: The valve body is compact, and the sealing ring is generally movable for easy replacement.
· Wide application range: Suitable for conditions from vacuum to high pressure and from small to large diameters, as well as various media such as water, oil and gas.
· Fireproof and antistatic: Specially designed ball valves feature fireproof structure (metal sealing remains effective after soft seal burnout) and antistatic function (ensuring static electricity discharge).
· Poor flow regulation performance: Due to its quick-opening flow characteristic, it is not suitable for applications requiring precise flow adjustment.
· Clear full-open/full-close positioning: With a limit structure, the opening positions (full open/full close) are clearly indicated.
■ Technical Specifications
| Parameter Category | Specific Parameters | Unit/Description | Typical Range / Significance |
| Basic Specification | Nominal Diameter (DN) | mm | DN6 ~ DN800 (wide range; custom sizes available for larger diameters) |
| Nominal Pressure (PN) | MPa/Class | PN1.6 ~ PN32.0 (conventional), high pressure up to PN76.0 (Class 4500) | |
| Connection Type | - | Flanged, threaded, wafer, welded | |
| Structural Performance | Structure Type | - | Floating ball type, fixed ball type, three-way type, V-port ball valve (for regulation) |
| Valve Body Type | - | One-piece, two-piece, three-piece (mainstream) | |
| Flow Coefficient (Kv / Cv) | m³/h | Extremely high, close to straight pipe; specific values to be checked in tables | |
| Leakage Class | ANSI/FCI | Class Ⅵ (soft seal, bubble-tight) or Class Ⅳ (metal seal) | |
| Fire-Safe Design | API 607/6FA | Standard type / fire-safe type (fire-safe type maintains basic sealing after fire) | |
| Antistatic Design | - | With / Without (ensures static discharge between ball and stem) | |
| Material & Medium | Valve Body Material | - | WCB carbon steel, 304/316 stainless steel, alloy steel, brass, PVC, etc. |
| Ball Material | - | 304/316 stainless steel, usually chrome-plated or hardfaced | |
| Seat Seal Material | - | PTFE, RPTFE, PEEK, metal (Stellite alloy, etc.) | |
| Suitable Medium | - | Water, steam, oil products, natural gas, acid/alkali liquid, slurry, etc. | |
| Medium Temperature Range | ℃ | -196℃ ~ +550℃ (wide range, depending on seat material) | |
| Operation & Actuation | Operation Mode | - | Lever, worm gear, pneumatic, electric, hydraulic |
| Operating Torque | N·m | Higher torque for floating ball, lower torque for fixed ball | |
| 90° Opening & Closing Time | s | Pneumatic / Electric: 1~10 seconds; Manual: instantaneous |
