Main Features
· Fast response: Acts instantly upon energization or de-energization, with response time at millisecond level.
· Simple control: Driven directly by electrical signals, easy to integrate with automation systems such as PLC.
· Compact structure: Small size and convenient installation, suitable for space-limited applications.
· Reliable sealing: Adopts elastic sealing materials with low internal leakage to ensure control accuracy.
· Energy-saving and durable: Low power consumption, only consuming power during switching; simple structure with low maintenance cost.
■ Technical Specifications
| Parameter Category | Specific Parameters | Unit / Description | Typical Range / Common Values |
| Basic Specification | Nominal Diameter (DN) | mm | Commonly DN1 ~ DN50, micro valves can be smaller than 1 mm |
| Connection Type | - | Pipe threads (G/NPT), flanged, quick-connect fittings | |
| Valve Body Material | - | Brass, stainless steel (304/316), plastic (PP/PTFE) | |
| Electrical Characteristics | Operating Voltage | V | DC24V (most common), DC12V, AC220V, AC110V |
| Power Consumption | W | DC type: 1~5W; AC type: 5~20W | |
| Insulation Class | - | Class B/F/H (thermal class) | |
| Explosion‑proof Class | - | Ex d IIC T6 (for explosion-proof type only) | |
| Ingress Protection Rating | IP | IP65/IP67 (dustproof and waterproof) | |
|
Performance Parameters |
Operating Pressure Range | MPa | 0~1.0 MPa (standard pneumatic), high-pressure type up to 10 MPa |
| Minimum Operating Pressure | MPa | 0.02~0.1 MPa (special design required for zero-pressure differential start) | |
| Medium Temperature Range | ℃ | -10℃ ~ +80℃ (standard type), high-temperature type -40℃ ~ +200℃ | |
| Ambient Temperature Range | ℃ | -20℃ ~ +50℃ (allowable operating range for coil) | |
| Response Time | ms | 10~50 ms (from energization/de-energization to valve actuation completion) | |
| Leakage Rate | mL/min | ≤ 0.1 mL/min (for high sealing requirements) | |
| Service Life | Million cycles | 1,000,000 ~ 10,000,000 cycles (depending on working conditions and quality) | |
| Medium & Function | Suitable Medium | - | Compressed air, inert gas, fuel gas, steam, etc. |
| Medium Viscosity | cSt | Generally required ≤ 50 cSt (special design required for higher viscosity) | |
| Actuation Mode | - | Normally Closed (NC), Normally Open (NO), latching type | |
| Valve Position Function | - | 2/2-way, 3/2-way, 5/3-way, etc. | |
| Manual Function | - | With manual override button (for emergency use / commissioning) | |
| Filtration Requirement | μm | Front-end filtration required; generally particle size ≤ 40 μm |
